MA37 Fully Automatic Infrared Moisture Analyzer

Max. weighing capacity

70 g

Reproducibility, typical

For initial sample weights of approx.  1 g: -/+ 0.2% For initial sample weights of approx.  5 g: -/+ 0.05%

Readability

1 mg, 0.01%

Typical sample quantity

5 g - 15 g

Display modes for results

Moisture content in %M and g / dry weight in %S and g / ATRO (ratio) in %M/S

Temperature range and settings

40 deg C - 200 deg  C, in increments of 1 deg C Standby temperature selectable from 50 deg C - 120 deg C

Sample heating

Infrared metal heating elements

Heating programs

Standard drying, gentle drying, MA35 mode

Shutoff parameter

Choice of modes:

Fully automatic

Semiautomatic mg (1 mg - 50 mg/ 5 sec. - 300 sec.)

 Semiautomatic % (0.1% - 5.0%/ 5 sec. - 300 sec.)

 Timer settings (02:00 - 99.59 min.)

Manua

Access to sample chamber

Removable hood with wide opening angle Soft Close mechanism

Measuring program

1 program saved in the non - volatile memory (user - definable method parameters)

Memory for data storage

Results are saved until the start of the next measurement

Operator guidance features

Intuitive user interface, including touch screen and easy - to - understand menu prompts

Languages selectable in menu

English set as the default; can be changed in the menu to Chinese, French, Italian, Japanese, Polish, Portuguese, Russian, Spanish and Turkish

Status light

Displays the status  inchanalys is running/START, inch  inchanalys is completed/STOP inch or  inchanalys is error inch

Sample inspection

LED - illuminated sample chamber inspection window with grid above the hood

Draft shield

Integrated draft shield

Cleaning

Removable hood, grid and sample chamber plate for easy cleaning in a laboratory dishwasher

Printout

Printout using the optional, internal printer YDP30 alternatively, the printer YDP20 - OCE can be used with an adapter (YCC03 - D09)

GLP - compliant, inalterable standard for printout of the results paper - saving mode for short record

Performance test

Menu function for testing the analyzers performance using a ReproEasy pad

Monitoring and control of the accuracy of the analyzer as inspection, measuring and test equipment

External calibration using optional calibration weights Temperature adjustment with optional adjustment set

Data interface

Mini USB port

Automatic detection of the Sartorius printers YDP30 and YDP40

Direct data transfer to Microsoft Office programs without any additional software

Programmable data output interval

SBI data transfer protocol

Frequency

50/60 Hz

Power consumption

Max. 640 VA

Temperature range

10 deg C to 30 deg C

Housing dimensions (W + D + H)

215 + 400 + 210 mm (8.5 inch + 15.7 inch + 8.3 inch)

Weight

Approx. 6.2 kg (approx. 13.6 lbs.)
